TIMKEN -Torrington HJ-364828.2RS with seals, Needle Roller bearing,Cylindrical Roller Radial Bearings-HJ-2RS Series 57,150 X 76,200 X 44,45 (mm)

DIMENSIONS AND LOAD RATINGS
Fw Bore		D Outside Diameter		C Width		Bearing* Designation	Load Ratings			§ Limiting Speed	ra* Housing Fillet		† Used with Inner Ring Designation
							Basic Dynamic Cr		Basic Static CO
								ISO	ISO
(nom.)		(nom.)		(nom.)			T	281	76		(max.)
inch	mm	inch	mm	inch	mm	(with both seals)	lbf	lbf	lbf	rpm	inch	mm
0.6250	15,875	1.1250	28,570	1.000	25,40	HJ-101816.2RS	2 970	3 980	4 150	6 100	0.025	0,6	—
0.7500	19,050	1.2500	31,750	1.000	25,40	HJ-122016.2RS	3 170	4 250	4 680	5 100	0.04	1,0	IR-081216
0.8750	22,225	1.3750	34,925	1.000	25,40	HJ-142216.2RS	3 540	4 750	5 600	4 400	0.04	1,0	IR-101416
1.0000	25,400	1.5000	38,100	1.000	25,40	HJ-162416.2RS	3 870	5 200	6 520	3 800	0.04	1,0	IR-121616 IR-131616
1.1250	28,575	1.6250	41,275	1.250	31,75	HJ-182620.2RS	5 740	7 700	11 200	3 400	0.04	1,0	IR-141820 IR-151820
1.2500	31,750	1.7500	44,450	1.250	31,75	HJ-202820.2RS	5 900	7 920	11 900	3 100	0.04	1,0	IR-162020
1.3750	34,925	1.8750	47,625	1.250	31,75	HJ-223020.2RS	6 290	8 430	13 300	2 800	0.04	1,0	IR-182220
1.5000	38,100	2.0625	52,388	1.250	31,75	HJ-243320.2RS	7 400	9 930	14 800	2 500	0.06	1,5	IR-192420 IR-202420
1.6250	41,275	2.1875	55,562	1.250	31,75	HJ-263520.2RS	7 600	10 200	15 700	2 400	0.06	1,5	IR-212620 IR-222620
1.7500	44,450	2.3125	58,738	1.250	31,75	HJ-283720.2RS	7 790	10 500	16 600	2 200	0.06	1,5	IR-222820 IR-232820 IR-242820
2.0000	50,800	2.5625	65,088	1.250	31,75	HJ-324120.2RS	8 410	11 300	19 100	1 900	0.06	1,5	IR-243220 IR-253220 IR-263220 IR-273220
2.2500	57,150	3.0000	76,200	1.750	44,45	HJ-364828.2RS	14 800	19 900	36 200	1 700	0.06	1,5	IR-283628
2.5000	63,500	3.2500	82,550	1.750	44,45	HJ-405228.2RS	16 000	21 500	41 300	1 500	0.08	2,0	IR-314028 IR-324028
2.7500	69,850	3.5000	88,900	1.750	44,45	HJ-445628.2RS	16 700	22 300	44 800	1 400	0.08	2,0	IR-354428 IR-364428
3.0000	76,200	3.7500	95,250	1.750	44,45	HJ-486028.2RS	17 700	23 800	49 900	1 300	0.08	2,0	IR-384828 IR-404828



BEARING MOUNTING DIMENSIONS
Mounting Dimensions, Clearance Fit									Mounting Dimensions, Tight Transition Fit
Inch Mounting				Metric Mounting(mm)					Inch Mounting				Metric Mounting(mm)
S Shaft Raceway Diameter		H Housing Bore Diameter		S Shaft Raceway Diameter		H Housing Bore Diameter		Bearing Designation	S Shaft Raceway Diameter		H Housing Bore Diameter		S Shaft Raceway Diameter		H Housing Bore Diameter
max.	min.	min.	max.	max.	min.	min.	max.		max.	min.	min.	max.	max.	min.	min.	max.
0.6250	0.6246	1.1250	1.1258	15,875	15,865	28,575	28,595	-101816	0.6244	0.6240	1.1239	1.1247	15,860	15,850	28,547	28,567
0.7500	0.7495	1.2500	1.2510	19,050	19,037	31,750	31,775	-122016	0.7492	0.7487	1.2487	1.2497	19,030	19,017	31,717	31,742
0.8750	0.8745	1.3750	1.3760	22,225	22,212	34,925	34,950	-142216	0.8742	0.8737	1.3737	1.3747	22,205	22,192	34,892	34,917
1.0000	0.9995	1.5000	1.5010	25,400	25,387	38,100	38,125	-162416	0.9992	0.9987	1.4987	1.4997	25,380	25,367	38,067	38,092
1.1250	1.1245	1.6250	1.6260	28,575	28,562	41,275	41,300	-182620	1.1242	1.1237	1.6237	1.6247	28,555	28,542	41,242	41,267
1.2500	1.2494	1.7500	1.7510	31,750	31,735	44,450	44,475	-202820	1.2490	1.2484	1.7487	1.7497	31,725	31,710	44,417	44,442
1.3750	1.3744	1.8750	1.8760	34,925	34,910	47,625	47,650	-223020	1.3740	1.3734	1.8737	1.8747	34,900	34,885	47,592	47,617
1.5000	1.4994	2.0625	2.0637	38,100	38,085	52,388	52,418	-243320	1.4990	1.4984	2.0610	2.0622	38,075	38,060	52,349	52,379
1.6250	1.6244	2.1875	2.1887	41,275	41,260	55,562	55,592	-263520	1.6240	1.6234	2.1860	2.1872	41,250	41,235	55,524	55,554
1.7500	1.7494	2.3125	2.3137	44,450	44,435	58,738	58,768	-283720	1.7490	1.7484	2.3110	2.3122	44,425	44,410	58,699	58,729
2.0000	1.9993	2.5625	2.5637	50,800	50,782	65,088	65,118	-324120	1.9988	1.9981	2.5610	2.5622	50,770	50,752	65,049	65,079
2.2500	2.2493	3.0000	3.0012	57,150	57,132	76,200	76,230	-364828	2.2488	2.2481	2.9985	2.9997	57,120	57,102	76,162	76,192
2.5000	2.4993	3.2500	3.2514	63,500	63,482	82,550	82,586	-405228	2.4988	2.4981	3.2481	3.2495	63,470	63,452	82,502	82,538
2.7500	2.7493	3.5000	3.5014	69,850	69,832	88,900	88,936	-445628	2.7488	2.7481	3.4981	3.4995	69,820	69,802	88,852	88,888
3.0000	2.9993	3.7500	3.7514	76,200	76,182	95,250	95,286	-486028	2.9988	2.9981	3.7481	3.7495	76,170	76,152	95,202	95,238

The Timken-Torrington HJ-364828.2RS is a high-performance needle roller bearing with dual seals, specifically designed to offer superior load capacity, compact design, and robust protection from environmental contaminants. This bearing is part of the Timken-Torrington series known for its durability and efficiency, making it a popular choice in applications such as automotive transmissions, industrial machinery, and heavy equipment where space efficiency, load handling, and protection from contaminants are essential.

Size and Weight:

The HJ-364828.2RS has a bore diameter of approximately 2.25 inches (57.15 mm), an outer diameter of 3 inches (76.2 mm), and a width of 1.5 inches (38.1 mm). The compact size of this bearing allows it to fit into tight spaces without sacrificing its load-bearing capabilities. Despite its robust load-handling capacity, the bearing maintains a relatively lightweight profile, which is advantageous in applications where reducing the overall weight of the equipment is important. This compact and lightweight nature makes the HJ-364824.2RS an ideal component for applications that require both high performance and space optimization.

Performance:

The HJ-364828.2RS is engineered to handle high radial loads with efficiency and reliability. The bearing features needle rollers made from high-quality, hardened steel, which are longer than their diameter. This design maximizes the contact surface area, allowing the bearing to support substantial loads while maintaining minimal friction and wear. The dual seals (2RS) are integral to the bearing’s performance, as they protect the internal components from contaminants such as dirt, dust, and moisture. These seals also help retain the lubricant within the bearing, ensuring consistent lubrication, reducing maintenance frequency, and extending the operational lifespan of the bearing.

The dual-seal configuration is particularly beneficial in high-speed or high-load applications, as it minimizes the risk of lubricant leakage and prevents contaminants from entering the bearing. This not only enhances the bearing’s performance but also contributes to the overall reliability and longevity of the machinery it is used in.

Usage:

The HJ-364828.2RS is suitable for a wide range of applications where space constraints, high load capacity, and protection from contaminants are critical. It is commonly used in automotive transmissions, where its compact design and load-handling capabilities are ideal for efficient power transmission. In industrial machinery, the bearing’s robust construction and sealing make it suitable for gearboxes, conveyors, and other equipment that operates under high loads and requires minimal maintenance.

In heavy equipment, such as construction and agricultural machinery, the bearing’s ability to perform reliably under heavy loads and harsh conditions makes it a preferred choice. The dual seals ensure that the bearing remains protected in environments where exposure to dust, dirt, and moisture is common, thereby reducing the risk of premature failure and downtime.

Structure：

The structure of the HJ-364828.2RS includes a robust cage that holds the needle rollers in place, ensuring stable operation and efficient load distribution. The needle rollers are precisely aligned within the cage to minimize friction and ensure smooth operation. The dual rubber seals on both sides of the bearing provide a barrier against external contaminants, while also retaining the lubricant inside. This sealed design reduces noise and vibration during operation, contributing to smoother, quieter performance.

The bearing’s design also allows for easy installation and removal, which is beneficial during maintenance or replacement. The compact and sealed structure ensures that the bearing fits well into confined spaces, making it versatile for a variety of machinery and equipment layouts.

Conclusion:

The Timken-Torrington HJ-364828.2RS needle roller bearing is a versatile, high-performance solution for applications that demand high load capacity, compact design, and reliable protection from contaminants. Its robust construction, efficient sealing, and ease of maintenance make it an excellent choice for engineers and technicians seeking dependable bearing solutions for demanding environments. Whether in automotive, industrial, or heavy equipment applications, the HJ-364824.2RS offers exceptional performance, durability, and longevity, ensuring reliable operation and reduced maintenance needs across a wide range of industrial uses.
