TIMKEN -Torrington HJ-202820.2RS with seals, Needle Roller bearing,Cylindrical Roller Radial Bearings-HJ-2RS Series 31,750 X 44,450X 31,75 (mm)

ENQUIRY!
Brand:
Stock: In stock
Email:sale@northbearings.com
Category:

Description

Fw Bore (nom.) inch1.2500
Fw Bore (nom.) mm31,750
D Outside Diameter (nom.) inch1.7500
D Outside Diameter (nom.) mm44,450
C Width (nom.) inch1.250
C Width (nom.) mm31,75
§ Limiting Speed3 100
ra* Housing Fillet (max.) inch0.04
ra* Housing Fillet (max.) mm1,0
Used with Inner Ring DesignationIR-162020

DIMENSIONS AND LOAD RATINGS

Fw

Bore

D

Outside Diameter

C

Width

Bearing* DesignationLoad Ratings§

Limiting Speed

ra*

Housing Fillet

†

Used with Inner Ring Designation

Basic Dynamic

Cr



Basic Static

CO

 ISOISO
(nom.)(nom.)(nom.) T28176 (max.)
inchmminchmminchmm(with both seals)lbflbflbfrpminchmm
0.625015,8751.125028,5701.00025,40HJ-101816.2RS2 9703 9804 1506 1000.0250,6—
0.750019,0501.250031,7501.00025,40HJ-122016.2RS3 1704 2504 6805 1000.041,0IR-081216
0.875022,2251.375034,9251.00025,40HJ-142216.2RS3 5404 7505 6004 4000.041,0IR-101416
1.0000



25,400



1.5000



38,100



1.000



25,40



HJ-162416.2RS



3 870



5 200



6 520



3 800



0.04



1,0



IR-121616

IR-131616

1.1250



28,575



1.6250



41,275



1.250



31,75



HJ-182620.2RS



5 740



7 700



11 200



3 400



0.04



1,0



IR-141820

IR-151820

1.250031,7501.750044,4501.25031,75HJ-202820.2RS5 9007 92011 9003 1000.041,0IR-162020
1.375034,9251.875047,6251.25031,75HJ-223020.2RS6 2908 43013 3002 8000.041,0IR-182220
1.5000



38,100



2.0625



52,388



1.250



31,75



HJ-243320.2RS



7 400



9 930



14 800



2 500



0.06



1,5



IR-192420

IR-202420

1.6250



41,275



2.1875



55,562



1.250



31,75



HJ-263520.2RS



7 600



10 200



15 700



2 400



0.06



1,5



IR-212620

IR-222620

1.7500





44,450





2.3125





58,738





1.250





31,75





HJ-283720.2RS





7 790





10 500





16 600





2 200





0.06





1,5





IR-222820

IR-232820

IR-242820

2.0000







50,800







2.5625







65,088







1.250







31,75







HJ-324120.2RS8 410







11 300







19 100







1 900







0.06







1,5







IR-243220

IR-253220

IR-263220

IR-273220

2.250057,1503.000076,2001.75044,45HJ-364828.2RS14 80019 90036 2001 7000.061,5IR-283628
2.5000



63,500



3.2500



82,550



1.750



44,45



HJ-405228.2RS



16 000



21 500



41 300



1 500



0.08



2,0



IR-314028

IR-324028

2.7500



69,850



3.5000



88,900



1.750



44,45



HJ-445628.2RS



16 700



22 300



44 800



1 400



0.08



2,0



IR-354428

IR-364428

3.0000



76,200



3.7500



95,250



1.750



44,45



HJ-486028.2RS



17 700



23 800



49 900



1 300



0.08



2,0



IR-384828

IR-404828



BEARING MOUNTING DIMENSIONS

Mounting Dimensions, Clearance Fit Mounting Dimensions, Tight Transition Fit
Inch MountingMetric Mounting(mm) Inch MountingMetric Mounting(mm)
S

Shaft Raceway Diameter

H

Housing Bore Diameter

S

Shaft Raceway Diameter

H

Housing Bore Diameter

Bearing DesignationS

Shaft Raceway Diameter

H

Housing Bore Diameter

S

Shaft Raceway Diameter

H

Housing Bore Diameter

max.min.min.max.max.min.min.max.max.min.min.max.max.min.min.max.
0.62500.62461.12501.125815,87515,86528,57528,595-1018160.62440.62401.12391.124715,86015,85028,54728,567
0.75000.74951.25001.251019,05019,03731,75031,775-1220160.74920.74871.24871.249719,03019,01731,71731,742
0.87500.87451.37501.376022,22522,21234,92534,950-1422160.87420.87371.37371.374722,20522,19234,89234,917
1.00000.99951.50001.501025,40025,38738,10038,125-1624160.99920.99871.49871.499725,38025,36738,06738,092
1.12501.12451.62501.626028,57528,56241,27541,300-1826201.12421.12371.62371.624728,55528,54241,24241,267
1.25001.24941.75001.751031,75031,73544,45044,475-2028201.24901.24841.74871.749731,72531,71044,41744,442
1.37501.37441.87501.876034,92534,91047,62547,650-2230201.37401.37341.87371.874734,90034,88547,59247,617
1.50001.49942.06252.063738,10038,08552,38852,418-2433201.49901.49842.06102.062238,07538,06052,34952,379
1.62501.62442.18752.188741,27541,26055,56255,592-2635201.62401.62342.18602.187241,25041,23555,52455,554
1.75001.74942.31252.313744,45044,43558,73858,768-2837201.74901.74842.31102.312244,42544,41058,69958,729
2.00001.99932.56252.563750,80050,78265,08865,118-3241201.99881.99812.56102.562250,77050,75265,04965,079
2.25002.24933.00003.001257,15057,13276,20076,230-3648282.24882.24812.99852.999757,12057,10276,16276,192
2.50002.49933.25003.251463,50063,48282,55082,586-4052282.49882.49813.24813.249563,47063,45282,50282,538
2.75002.74933.50003.501469,85069,83288,90088,936-4456282.74882.74813.49813.499569,82069,80288,85288,888
3.00002.99933.75003.751476,20076,18295,25095,286-4860282.99882.99813.74813.749576,17076,15295,20295,238

The Timken HJ-202820.2RS is a high-precision needle roller bearing designed to offer robust performance in compact applications where high load capacity and reduced friction are essential. This bearing belongs to the family of drawn cup needle roller bearings, known for their thin-walled outer rings and full complement of needle rollers that maximize load-bearing capability while minimizing overall size.

One of the standout features of the HJ-202820.2RS is its integrated rubber seals (denoted by “2RS”), which are positioned on both sides of the bearing. These seals provide effective protection against contaminants such as dust, dirt, and moisture, enhancing the bearing’s reliability and longevity, particularly in harsh operating environments. The seals also help to retain lubrication, reducing the need for frequent maintenance and ensuring smooth, quiet operation over extended periods.

The HJ-202820.2RS has an inside diameter of 31.75 mm, an outside diameter of 44.45 mm, and a width of 31.75 mm. Its compact design makes it ideal for use in applications such as automotive transmissions, pumps, compressors, and various industrial machinery where space is limited but high performance is required. The full complement of needle rollers allows the bearing to carry significant radial loads, and its precision-engineered rollers ensure minimal friction and heat generation, even at high speeds.

Constructed from high-quality steel, the HJ-202820.2RS offers excellent durability and resistance to wear, making it suitable for demanding applications. The bearing’s drawn cup design simplifies installation, allowing it to be easily press-fitted into a housing bore, which also reduces the overall assembly footprint.

Overall, the Timken HJ-202820.2RS is a versatile and durable needle roller bearing that combines high load capacity, compact design, and effective sealing to deliver reliable performance in a wide range of demanding applications.
